Description:

Standard Features:

• OHV design with steel cylinder liner, ball bearing supported crankshaft and float type carburetor
• Automatic decompressor
• Large muffler for quiet operation
• Durable recoil starter
• Oil drain / on two sides of the engine for different applications
• Meets US EPA and CARB emission regulations

Options

• Various crankshaft PTO configurations to fit most applications

Applications

• Water Pumps
• Generators
• Small Construction Equipment such as Plate Tampers
• Garden Tillers
• Wood Splitters
• Small Turf Equipment

Warranty

• 3 year limited warranty

Specifications:

• SKU: GX120QX
• PTO Shaft: 3/4" diameter
• Starter: Recoil
• Air Cleaner: Dual Element
• Oil Alert: Yes
• Notes: Not specified (indicated by dash "-")
• Dry Weight: 13.2 kg / 29 lbs
• Engine Type: Air-cooled, 4-Stroke, OHV, single cylinder
• Bore x Stroke: 60 x 42 mm (2.4 x 1.7 in)
• Displacement: 118 cm³ (7.2 cu in)
• Compression Ratio: 8.5 : 1
• Net Horsepower Output: 2.6 kW (3.5 HP) at 3,600 rpm
• Net Torque: 7.3 Nm (5.4 lbs ft) at 2,500 rpm
• PTO Shaft Rotation: Counterclockwise (from PTO shaft side)
• Ignition System: Transistorized magneto ignition
• Carburetor: Horizontal type butterfly valve
• Lubrication System: Forced Splash
• Governor System: Centrifugal Mechanical
• Oil Capacity: 0.6 l (0.63 US qt, 0.53 Imp qt)
• Fuel Tank Capacity: 2.0 l (2.1 US qt)
• Dimensions (L x W x H): 305 x 341 x 318 mm (12.0 x 13.4 x 12.5 in)
