Description:

The GX270 engine is suitable for a wide range of heavy-duty applications such as construction equipment, tillers, generators, welders, pumps and other industrial applications.

Features:

• The OHV design enhances combustion efficiency
• A variable ignition timing (digital CDI) results in high power output, reduced fuel consumption and excellent exhaust emissions performance.
• Easy starting with an automatic decompression system and an easy-to-grip soft recoil starter handle
• High quality materials and purpose-built components ensure reliable long-term use
• Meets world's most stringent environmental legislation
• Guaranteed low fuel and oil consumption
• Reduced vibration and noise level

Specification:

• Engine Type: Air-cooled, 4-Stroke, OHV, single cylinder
• Bore x Stroke: 77 x 58 mm (3.0 x 2.3 in)
• Displacement: 270 cm3 (16.5 cu in)
• Compression Ratio: 8.2 : 1
• Net Horsepower Output: 6.0 kW (8.0 HP) at 3,600 rpm
• Net Torque: 17.7 Nm (13.1 lbs ft) at 2,500 rpm
• PTO Shaft Rotation: Counterclockwise (from PTO shaft side)
• Ignition System: Transistorized magneto ignition
• Carburetor: Horizontal type butterfly valve
• Lubrication System: Forced Splash
• Governor System: Centrifugal Mechanical
• Oil Capacity: 1.1 l (1.16 US qt, 0.97 Imp qt)
• Fuel Tank Capacity: 5.3 l (5.6 US qt)
• Dimensions (L x W x H): 380 x 430 x 410 mm (15.0 x 16.9 x 16.1 in)
