Description:

Features

• Efficient and compact overhead valve design
• Durable ball bearing crankshaft
• Electronic ignition and automatic decompressor for easier starting
• Heavy duty recoil starter
• 2 sided oil drain/ filler cap for varied applications
• Large standard muffler for quiet operation

Options

• D.C. electric start
• Cyclone, oil bath , snorkel and dual element air filter options
• 1 ~ 18 amp battery charging systems
• Larger mufflers for even quieter operation

Applications

• Industrial Equipment
• Heavy Duty Construction Equipment
• Generators
• Water Pumps
• Portable Saw Mills
• Industrial Pressure Washers

Specification:

• Engine Type: Air-cooled, 4-Stroke, OHV, single cylinder
• Bore x Stroke: 88 x 64 mm (3.5 x 2.5 in)
• Displacement: 389 cm3 (23.7 cu in)
• Compression Ratio: 8.0 : 1
• Net Horsepower Output: 8.2 kW (11.0 HP) at 3,600 rpm
• Net Torque: 25.1 Nm (18.5 lbs ft) at 2,500 rpm
• PTO Shaft Rotation: Counterclockwise (from PTO shaft side)
• Ignition System: Transistorized magneto ignition
• Carburetor: Horizontal type butterfly valve
• Lubrication System: Forced Splash
• Governor System: Centrifugal Mechanical
• Oil Capacity: 1.1 l (1.16 US qt, 0.97 Imp qt)
• Fuel Tank Capacity: 6.1 l (6.4 US qt)
• Dimensions (L x W x H): 405 x 450 x 443 mm (15.9 x 17.7 x 17.4 in)
