Description:

Honda’s GX series engines are legendary for superior reliability and performance. And there’s no doubt about it: the GX120, 160, and 200 live up to the legend. Low noise levels, low vibration, and low emissions – without sacrificing power output or performance.

Specifications:

Engine Type

• Model: GX160
• Type: Air-cooled 4-stroke OHV (Overhead Valve)
• Bore x Stroke: 68 x 45 mm
• Displacement: 163 cc
• Net Power Output: 4.8 HP (3.6 kW) @ 3,600 RPM
• Net Torque: 7.6 lb-ft (10.3 Nm) @ 2,500 RPM
• PTO Shaft Rotation: Counterclockwise (from PTO side)

Key Features

• Compression Ratio: 9.0:1
• Carburetor: Butterfly type
• Ignition System: Transistorized magneto
• Starting System: Recoil starter
• Lubrication: Splash system
• Governor: Centrifugal mechanical
• Air Cleaner: Dual-element (better dust filtration)

Fuel & Oil

• Fuel Type: Unleaded (86 octane or higher)
• Fuel Tank Capacity: 3.3 U.S. qts (3.1 liters)
• Oil Capacity: 0.61 US qt. (0.58 L)
• Recommended Oil: SAE 10W-30 (varies by climate)

Dimensions & Weight

• Length: 12.2" (312 mm)
• Width: 14.3" (362 mm)
• Height: 13.6" (346 mm)
• Dry Weight: 33 lbs (15.1 kg)

Electrical Options

• Lamp/Charge Coil Options: 50W / 1A, 7A, 18A

Durability & Compliance

• Warranty: Varies by region (typically 2-3 years consumer use)
• California Prop 65 Warning: Yes (contains chemicals known to cause cancer/reproductive harm)
